NETRACK
The broad range of NetRACK wall racks have been designed for
use with installations, electronic and computer equipment that
require a robust rack with limited volume, that can easily be
installed on walls.
Quick and easy installation. Allows units to be placed in
positions that allow the optimal use of surface area, using
construction and assembly systems with demonstrated
operation, such as the "Springswivel" hinge. With a
detailed
appearance, it harmonises and complements interiors in
commercial premises and offices.
Its standard heights of 6, 9, 12 and 15 U, combined with 4 different
depth options, 250, 350, 400 and 500 mm, allow one to select the
ideal wall rack for each installation.
Standard finishes: central and rear body epoxy paint similar
to
RAL 9002. Doorframe, 19" sections and rear panel epoxy paint
similar to RAL 7030.
Recommended load capacities: 40 Kg on NETRACK 1 body models
and 20 Kg on the central body of NETRACK 2 body models or with
19"
pivoting chassis.
Delivery: assembled, ready to install with wall-fastening template.
|
